M12-2 Hardware Spec

FUJITSU SPARC M12-2 SERVER SPECIFICATIONS

Processor

• 12-core, 3.0 GHz SPARC64 XII processor
• Dual-instruction pipeline per core
• 96 threads per processor (8 threads per core)
• 96 integer execution units per processor (8 per core)
• 96 floating-point units per processor (8 per core)
• Random number generator (1 per processor)

Cache per Processor

• Level 1: instruction: 64 KB, data: 64 KB per core
• Level 2: 512 KB per core
• Level 3: 32 MB per processor

System Configuration

• Fujitsu SPARC M12-2 servers are configured with one or two SPARC64 XII
• Up to 24 dual inline memory module (DIMM) slots per processor using 16, 32 GB DIMMs
• 3 TB maximum memory configuration with 64 GB DIMMs

System Architecture

• SPARC V9 architecture, ECC protected

INTERFACES

• Network: 10/100/1000 Mb/sec, 1 Gb/sec, 10 Gb/sec, IEEE 802 San (10GBASE-T) standard, auto-negotiating
• Data and internal storage: 8 Gb Fibre Channel or SAS controllers providing hardware RAID 0, 1, and 1E/10 (ZFS file system provides higher levels of RAID)
• Expansion bus: 11 low-profile PCIe 3.0 (1.8) slots
• PCI Expansion Units: Up to 35 slots (with three PCI expansion units connected)
  • 1 CPU: Up to 51 slots (with four PCI expansion units connected)
  • 2 CPUs: Up to 91 slots (with eight PCI expansion units connected)
• Ports: Ethernet: four 1000Base-T (RJ45) network ports, one RJ45 serial management port, two USB ports for maintenance only
• Administration interface: two 1000Base-T (RJ45) network ports, one RJ45 serial management port, two USB ports for maintenance only

MASS STORAGE AND MEDIA

Internal storage:

• Up to eight 2.5-inch SAS 2 drives
• 600 GB or 1.2 TB hard disk drives (HDD)
• 400 GB or 800 GB solid state drives (SSD)

External storage:

• Optional external DVD drive
• Oracle offers a complete line of best-in-class, innovative storage, hardware, and software solutions, along with renowned world-class service and support. For more information, please refer to oracle.com/storage

POWER SUPPLY

• Four hot-swappable AC 1800 W redundant (2 + 2) power supplies
• Voltage 200 to 240 VAC, frequency 50/60 Hz
• Maximum operating input current at 200 VAC: 15.2 A
• Maximum operating input power at 200 VAC: 2,974 W

KEY RAS FEATURES

• Hot-pluggable ECC protection
• Guaranteed data path integrity
• Automatic recovery with predictive retry
• Dynamic L1, L2, and L3 cache way degradation
